Details
The Spur provides a sense of connection to the bike as if it were an extension to your body. Fast and efficient with an anti-gravity feel and laser-pointer precision that begs you to climb more, go farther, and descend anything you may encounter along the way. You'll instantly appreciate the free speed you're awarded while accelerating where you're usually accustomed to pedaling. Don't judge a book by its cover though, with all these lightweight and uphill oriented character traits the Spur requires no adjustment to descend like you're used to, you might actually go faster.
LIFETIME WARRANTY
Transition takes pride in the quality of its products and is stoked to offer a lifetime warranty for the original owner and its stellar crash replacement program. They have your back so you don't have to worry about your bike.
ALL CARBON FRAMESET
Full carbon frame made from premium Japanese Toray fiber with a tailored blend of 24T, 30T and 40T materials to create the right balance of frame stiffness, strength, and impact toughness. Our unique latex coated EPS molding process allows for sharper frame lines and tighter edge radius control with maximum strength to weight ratio and less wasted material.
PIVOT TECHNOLOGY
Collet main pivot technology improves rear end stiffness and keeps your pivot hardware tight. Additional bearing shields prevent main pivot bearing contamination when washing your bike or riding in wet conditions.
ENDURO MAX BEARINGS
Transition exclusively uses Enduro Max suspension pivot specific bearings in standard sizes that are readily available worldwide. Additional c-clips lock the rocker bearings in place under torsional loads.
FLEX STAY
Transition's flex stay system utilizes a carefully tuned carbon layup that removes pivot axles and bearings to save weight without compromising frame durability.
Specs
Frame | Spur Carbon 120mm |
---|---|
Fork | RockShox SID Select 120mm, 44mm Offset |
Headset | FSA No.57E |
Rear Shock | RockShox SIDLuxe Select |
Rims/Wheels | Stans Arch D |
Hubs | Shimano MT410-B |
Spokes | Pillar Double Butted |
Tires | Front: Maxxis Dissector 3C EXO (29x2.4), Rear: Maxxis Rekon 3C EXO (29x2.4) |
Crankset | Shimano Deore M6100 (32t/175mm) Small 170mm |
Chainwheel | 32T |
Chain | Shimano Deore M6100 |
Rear Derailleur | Shimano Deore M6100 |
Rear Cogs | Shimano Deore M6100 (10-51t) |
Shifters | Shimano Deore M6100 |
Handlebars | RaceFace Aeffect R (780mm x 20mm) |
Tape/Grips | ODI Elite Flow |
Stem | RaceFace Aeffect R (50mm) |
Brakes | Shimano Deore M6120, Shimano Deore RT64 (180/160mm) |
Saddle | ANVL Forge Cromo |
Seat Post | OneUp Dropper Post |
Accessories & Extras | Tubeless Valves & Sealant |
Color(s) | Black Powder |
Sizes | Small, Medium, Large, X-Large |
Weight | 29.4 lbs/13.3 kg (Size MD) |
* Subject to change without notice.
Videos
Transition - This is Spur Country
Part Numbers
Option | MPN | Store SKU |
---|---|---|
Black Powder / Large | 01.21.11.4444 | 210000083928 |
